FAS-113DG autosynchronizer

FAS-113DG is an autosynchronizer manufactured by DEIF that synchronizes the generator with the busbar and closes its switch when the voltage difference, slip frequency and phase Angle are within preset limits. The following are the detailed parameters and features of the product:

Main features:
Automatic synchronization: When the voltage difference, frequency difference and phase Angle difference are detected within the preset limit range, the generator switch is automatically turned on.
A variety of prime mover control: can control a variety of prime movers, by setting the control pulse width can be adapted to different models, including slow response diesel engines and fast response gas turbines.

Add to quote
Categories: ,

Description

Overview

Essential details：FAS-113DG autosynchronizer

Product Description

FAS-113DG is an autosynchronizer manufactured by DEIF that synchronizes the generator with the busbar and closes its switch when the voltage difference, slip frequency and phase Angle are within preset limits. The following are the detailed parameters and features of the product:

Main features:
Automatic synchronization: When the voltage difference, frequency difference and phase Angle difference are detected within the preset limit range, the generator switch is automatically turned on.
A variety of prime mover control: can control a variety of prime movers, by setting the control pulse width can be adapted to different models, including slow response diesel engines and fast response gas turbines.
Circuit breaker time compensation: with circuit breaker switching time compensation function.
Voltage control: Voltage control function.
LED status indicator: Provides LED display status, activation control and synchronization signals.
Flexible mounting: Support 35 mm DIN rail or base mounting.

FAS-113DG

Product parameter

Input voltage: 24V DC.
Output voltage: 0 ~ 10V DC.
Operating temperature range: -40℃ to +70℃.
Communication interface: Modbus RTU.

APPLICATION

FAS-113DG synchronizer is mainly used in power plants, ships, industry and other fields for synchronous generators and power grids. It can accurately measure the voltage, frequency and phase Angle of the generator and the grid, and when these parameters reach the preset synchronization conditions, send a signal to control the circuit breaker closure, so as to integrate the generator into the grid.

The product has been widely used in the field of industrial automation and process control for its high precision, strong anti-interference, flexible configuration and high reliability.
