IC698PSA350 GE High capacity power module

Description

Overview

Essential details：IC698PSA350 GE High capacity power module

Product Description

The IC698PSA350 is a high-capacity power module for the PACSystem RX7i controller family.
The module is used to provide the backplane power supply, which the module uses to activate the internal circuit and make it usable
Operate. The PSU occupies one slot in the chassis and is designed to be installed only on the RX7i
Frame in slot 0.
The input power supply voltage of the IC698PSA350 is 85 to 264 VAC and 100 to 150VD
C, the AC input frequency is 47 to 63 Hz. The module has a rated voltage of 120/240 V
AC and 125 VDC, the input power requirements are typical 440 watts and maximum 500 watts.
When used for AC input power, the power factor of this power module is 0.99.

IC698PSA350D

lf you need to inquire or purchase ,please send the product models to my email or call medirectly .

IC698PSA350 GE High capacity power module

The IC698PSA350 is a high-capacity power module for the PACSystem RX7i controller family. This module is used to provide the backplane power supply, which the module uses to activate the internal circuitry and make it operational. This power source
The module occupies one slot of the chassis and is designed to be installed only in slot 0 of the RX7i rack.
The IC698PSA350 has input power voltages of 85 to 264 VAC, 100 to 150VDC, and AC input frequencies of 47 to 63 Hz. The module is rated at 120/240 VAC and 125 VDC.
The input power requirements are typically 440 watts, with a maximum of 500 watts. When used for AC input power, the power factor of this power module is 0.99.
The IC698PSA350 is a single-slot power module that is installed in the leftmost slot or slot 0 of the RX7i rack. It is equipped with various LED status indicators to help identify the operating status of the module. These fingers
The lights include field normal, output normal and overheat indicators. The power module offers built-in protection circuits such as overheat and overvoltage protection as well as airflow protection. A 70 CFM forced air cooling fan is located in the system
The lower part of the chassis provides cooling air for power modules. If a stop in airflow is detected, the overheat LED indicator is activated.
