MMS3210/011-000 two-channel axial displacement transmitter

About the MMS3210/011-000 product, this is a two-channel axial displacement transmitter belonging to the MMS3000 transmitter series. Here are some details about the product:
Applications:
MMS3210/011-000 is mainly used to monitor axial displacement, shaft position, thermal expansion and radial displacement, thrust bearing and valve position. It is suitable for a variety of applications using eddy current displacement sensors.
The product is also suitable for combined measurements of two sensors, such as maximum measurements according to API670 or cone measurements and compensation measurements.
Add to quote
Categories: ,

Description

Overview

Essential details：MMS3210/011-000 two-channel axial displacement transmitter

Product Description

About the MMS3210/011-000 product, this is a two-channel axial displacement transmitter belonging to the MMS3000 transmitter series. Here are some details about the product:
Applications:
MMS3210/011-000 is mainly used to monitor axial displacement, shaft position, thermal expansion and radial displacement, thrust bearing and valve position. It is suitable for a variety of applications using eddy current displacement sensors.
The product is also suitable for combined measurements of two sensors, such as maximum measurements according to API670 or cone measurements and compensation measurements.
Applications include various types of turbomachinery, such as large and small steam turbines, fans, blowers, compressors, gearboxes, centrifuges, pumps, coal mills and others.
Input:
The input for the MMS3210/011-000 is the epro eddy current displacement sensor, which may include the PR6422/… , PR6423/… , PR6424/… , PR6425/… , and PR6426/… .
Features:
The MMS3210/011-000 converts two independent eddy current displacement sensor inputs into two independent outputs proportional to displacement.
System adaptability:
This system is not only suitable for power plant, refinery, chemical plant and other large equipment, can be combined with fieldbus and PLC, main computer and network together, but also suitable for small turbomachinery independent monitoring.
Security:
Please note that this transmitter is not explosion-proof.

MMS3120/022-000 9100-03047-01

Product parameter

Basic parameters:
Type: Dual channel axis displacement transmitter
Input: Suitable for epro vortex displacement sensors such as PR6422/… , PR6423/… , PR6424/… , PR6425/… , PR6426/…
Output: Two independent outputs proportional to displacement (usually 4-20mA or 0-10Vdc)
Technical specifications:
Power Supply: Usually AC/DC 24V, depending on the model
Power consumption: For details, see the product manual
Operating temperature range: -25°C to +70°C (may vary depending on the model)
Storage temperature range: -40°C to +85°C
Protection level: Usually IP65 or higher
Response time: milliseconds, depending on the combination of sensor and transmitter
Accuracy: Usually ±0.1% to ±0.5% of full scale, depending on the model and calibration
Linearity: High linearity ensures accurate measurement
Isolation: High isolation between channels and between power and output
Overload capability: The protection capability of the transmitter when the sensor is overloaded
Electromagnetic Compatibility (EMC) : complies with relevant EMC standards and requirements
Other features:
Diagnostic functions: May include fault diagnosis functions such as sensor open circuit, short circuit, and failure
Calibration: Support on-site or remote calibration
Interfaces: May include RS-485, HART and other communication interfaces for remote monitoring and data transmission
Mounting: Usually supports panel mounting or DIN rail mounting
Housing: Robust metal housing for high levels of protection

APPLICATION

The MMS3210/011-000 dual channel axial displacement transmitter is mainly used in various types of turbine-machinery, such as large and small steam turbines, fans, blowers, compressors, gear boxes, centrifuges, pumps, coal mills and other rotating machinery.
In addition, it can also be combined with the SZ-6 series magnetoelectric speed sensor to continuously monitor and measure the amplitude and intensity of bearing vibration of various rotating machinery. The transmitter provides a reliable solution for the measurement and protection control of the axis displacement of rotating machinery, and is widely used in power generation, petroleum, chemical industry, metallurgy and other sectors.
