1 Year Warranty
Description
Overview
Essential details：T8431 Trusted TMR 24Vdc Analogue Input Module ICS Triplex
Products Description
| Type: | Trusted TMR 24Vdc Analogue Input Module | Package: | Original |
|---|---|---|---|
| Warranty: | One-year | Condition: | New |
| Quality: | 10pcs | Stock: | In Stock |
| Shipping By: | DHLUPSFedexEMSTNTAramex. | ||
| High Light: |
8937-HN Fiber Optic Extender module GE |
||
Supply Ability
Supply Ability ： 100 Piece/Pieces per Day
Packing & Shipping
Package Type: New and original factory separately sealed inner box
Delivery time: Prepare delivery inventory;
The goods will be packed according to the international standard.
1. We will deliver the goods within 3 working days after payment.
2. The new and original factory seal the inner box separately
3. We can send it to you by DHL/TNT/UPS/EMS/ fedex.
Please contact us directly and we will deliver the goods according to your requirements. Best quality assurance
4. We promise that all goods we supply are 100% new and original
5. One year warranty (after delivery date).
Payment method: We accept telegraphic transfer
T8431
- Manufacturer : ICS Triplex
- Product No. : T8431
- System Supply Voltage Range : 20 to 32V dc
- Number of Inputs : 40 Channels
- User Defined Thresholds : 4-off
- Input Current Range : 0-22mA
- Input Voltage Range : 0-6 Vdc
- Sample Update Time : 0.5ms
- Resolution : 3.9uA (1/256mA)
- Safety Accuracy : +/- 1% of full scale
(default threshold above which 0x70nn series slice discrepancy faults are raised)
- Calibration Accuracy : 0.03%
- Recommended input channel calibration check
- interval : 2 years
- Circuit Type : Fault tolerant, fully triplicated with optional line monitoring
- Fusing : None, external if required
Intrinsic Safety External barrier
Sequence of Events
- Event Resolution : 1ms
- Time-stamp Accuracy : ±0.5 ms
- Field Common Isolation
- Sustained Working : ±250V dc
- Maximum Withstanding : ±2.5kV dc
- Channel to Channel Crosstalk : -40 to –60 dB
- Power Consumption : 15 – 18W
- Self-Test Interval : 2 minutes
- Operating Temperature : -5°C to 60°C (23°F to 140°F)
- Non-operating Temperature : -25°C to 70°C (-13°F to 158°F)
- Temperature change : 0.5ºC/min
- Operating Humidity : 10 – 95% RH non-condensing
- Environmental Specifications : Refer to Document 552517
- Dimensions
Height : 266mm (10.5ins)
Width : 31mm (1.2ins)
Depth : 303mm (12ins)
- Weight : 1.149kg (2.5lbs)
- Real Time Clock Resolution : 100µSec
- Shipping Weight : 2 Kg
Why Choose Us T8431 Trusted TMR 24Vdc Analogue Input Module ICS Triplex
Zhangzhou Branch of Xiamen Xiongba Electronic Commerce Co., Ltd. is a professional service provider in the field of industrial automation components. We mainly provide PLC module, DCS card, ESD system card, vibration monitoring system card, turbine control system module, gas generator components, we have established a close cooperative relationship with many PLC and DCS product maintenance service providers. The company has established an e-commerce operation model, which reduces the intermediate links for consumers and provides consumers with high-quality products and satisfactory services. The company has a complete logistics supply system. We can buy directly from abroad and supply equipment and spare parts from different countries and manufacturers to solve your problem.
| Sales Manager | SUNNY |
| sales@xiongbagk.cn | |
| (+86)-18059884797 | |
| Skype | SUNNY |
| Mobile | (+86)-18059884797 |
questions and answers
Q: Do you provide warranty for the goods?
A: Yes, we provide warranty for all the goods from us.
Q: Could you provide technology support?
A: We’re in this field more than 15 years. If there’s any problem, please contact with us,we’ll provide suggestion from our engineer to help you solve problem.
Q: Do you keeps goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.
Q:Does your goods are new and original ?
A: yes ,they are new and original
Superiority products T8431 Trusted TMR 24Vdc Analogue Input Module ICS Triplex
| BENTLY | GE | Yokogawa |
| 3500/60 163179-01 | UR8FH | Yokogawa PW481-10 |
| 3500/32 125712-01 | 269PLUS-100P-HI | Yokogawa PW482-50 |
| 3500/40M 140734-01 | UR8HH | Yokogawa SAI143-H33/PRP |
| 3500/15 127610-01 | SR469-P5-HI-A20-E | Yokogawa SAI143-S03 |
| 3500/22M 138607-01 | CB06551 PRD-B040SSIB-63 | Yokogawa SAI533-H33 |
| 3500/20 125744-02 | CB06551 | Yokogawa SAI533-H33/PRP |
| 3500/92 136180-01 | VMIVME-7455 | Yokogawa SB401-10 |
| 1900/65A-01-01-01-00-00 | VMIVME-4140 | Yokogawa SB401-50 |
| 3500/92 136180-01 | VMIVME-2128 | Yokogawa SCP451-53 |
| 3400/42M | IC695CHS016 | Yokogawa SDV144-S33 |
| 3500/15 106M1079-01 | E33NCHA-LNN-NS-00 | Yokogawa SDV531-L33 |
| 3500/15-07-00-00 | IC200PWR001D | Yokogawa SDV531-L33/STB4D-00 |
| 125720-01 | IC698CMX016 | Yokogawa SDV541-S33 |
