VM600 204-040-100-012 vibration monitoring

The VM600 204-040-100-012 is a vibration monitoring instrument produced by the Swiss company Vibro-Meter for a wide range of applications in industrial environments. Below are the detailed product details of this product:

Product name: Vibro-Meter VM600 204-040-100-012 module.
Input voltage: 24VDC.
Operating temperature: -20℃~+70℃.
Humidity range: 0 to 95%RH.
Vibration measurement range: 0~50mm/s.
Temperature measurement range: -50℃~+150℃.
Communication interface: RS485.

Add to quote
Categories: ,

Description

Overview

Essential details：VM600 204-040-100-012 vibration monitoring

Product Description

The VM600 204-040-100-012 is a vibration monitoring instrument produced by the Swiss company Vibro-Meter for a wide range of applications in industrial environments. Below are the detailed product details of this product:

Product name: Vibro-Meter VM600 204-040-100-012 module.
Input voltage: 24VDC.
Operating temperature: -20℃~+70℃.
Humidity range: 0 to 95%RH.
Vibration measurement range: 0~50mm/s.
Temperature measurement range: -50℃~+150℃.
Communication interface: RS485.
Technical specifications:
16 dynamic channels and 4 RPM channels.
Up to 20 processing outputs per dynamic channel and per dual channel (12 per xmc 16).
Capture data simultaneously on all channels using asynchronous (fixed frequency) or synchronous (sequential tracking) sampling.
24-bit data acquisition, high signal-to-noise ratio data processing, high-resolution FFT up to 6400 lines per 500 ms

VM600-ABE042

Product parameter

Design: Designed to work with VibroSight software.
Application: Widely used in the field of vibration monitoring of rotating machinery in petroleum, chemical, electric power, steel, cement and other industries.
Product size: 160mm x 80mm x 60mm.
Product weight: about 1kg.
Mounting method: wall mounted or plate mounted.
Power supply: 24VDC.
Storage capacity: Built-in 4GB memory card, can store 2 years of data.
Display: 2.4-inch TFT color display

APPLICATION

High precision: The use of high-precision sensors and advanced signal processing technology to achieve high-precision vibration monitoring.
High reliability: Rugged design and rigorous test procedures ensure stable operation in harsh environments.
High flexibility: Supports a variety of communication protocols and can be flexibly integrated into various application systems.
Easy to use: provides a friendly user interface and powerful programming functions for easy user operation and programming.
Functional perfection: Support a variety of vibration monitoring functions and data analysis functions to meet different application requirements
